TWISTER1500
The Powerful Floor Drying System
TWISTER1500
The Powerful Floor Drying System
TWISTER1500 is a powerful insulation drying system for drying water and moisture under the floor. The system rapidly dry large areas using either the injection of dry air or by suctioning water and moist air.
TWISTER1500 Applications
Underfloor water leak drying
Moisture drying
TWISTER1500 Highlights
Turbine Unit
Water Separator Unit
TWISTER1500 Specifications
Drying area
Up to 100 m2
Ambient temperature
Between -15°C and + 40°C
Water Separator Unit
Turbine Unit
Engine type
Side channel blower turbine
Blower housing
Die-cast aluminum alloy housing and impeller, IP55
RPM
2900 rpm (50 Hz) and 3,500 rpm (60 Hz)
Max capacity
210 m3/h (0 mbar pressure, 1.5 kW)
Max pressure
275 mbar (25 m3/h capacity, 2.2 kW)
Max noise level
70 dB(A)
Operational temperature range
-10°C to 50°C
Max humidity during operation
80 %
Electrical connection
230 Volt
Weight
40.4 kg
Dimensions
W44 cm x L45 cm x H45 cm (including legs)
Norms
Manufactured according to EN2006/42, EN ISO 12100:2010, EN 60204-I:2006, AC:2010, EN2014/35, EN2014/30, EN-61000-6-4:2007 and EN61000-6-2:2005 norms. Compliant to 2004/108/CE norm
Water Unit
Water Unit
Water tank capacity
30 liters
Max pump flow
2.8 liters/sec (~ 10 m3/h)
Max pumping height
7 m
Max particle size
10 mm
Water temperature range
Between 0°C to 40°C
Air filter
HEPA 13 filter with 99.95% efficiency in filtering 0.3 micron particles
Electrical connection
230 Volt
Weight
31 kg
Dimensions
W44 cm x L45 cm x H58 cm (including legs)
